V4-YST-GP16 SERIES

V4-YST-GP16 SERIES

by Gate Valve & StrainerHONEYWELLProduct

V4-YST-GP16 SERIES

Y-STRAINER

Features :

  • Cast iron body
  • Stainless steel filter stem
  • Flange EN1092-2, class 125
  • Screens are perforated 304 stainless steel with spot welded seam
  • Internally and externally fusion bonded epoxy powder coated (FGE)
  • Sizes : DN50 – DN600
  • Nominal pressure : 16 bar at -10ᵒC to 120ᵒ
  • Test pressure : Shell (Water) – 24 Bar
  • Test pressure : Seat (Water) -17.6 Bar
V5-GAR-GP16 SERIES

V5-GAR-GP16 SERIES

by Gate Valve & StrainerHONEYWELLProduct

V5-GAR-GP16 SERIES

Resilient Seated Gate Valve, Rising Stem (Hand Wheel)

Features :

  • Ductile Iron body
  • Stainless steel stem, metalseated
  • Full port type, lowest pressure lost
  • O-ring packing in up seal, no leakage
  • High strength thrust collar
  • Flange EN1092-2, class 125
  • Resilient sealing
  • Internally and externally fusion bonded epoxy powder coated (FBE)
  • Sizes : DN50- DN600
  • Nominal pressure : 16 bar at -10ᵒC to 120ᵒ
  • Test pressure : Shell (Water) – 24 Bar
  • Test pressure : Seat (Water) – 17.6 Bar
